Boron B Target
OVERVIEW
Boron B Target is a commonly used metal target in the semiconductor industry. Its purity can usually reach more than 99.99% (4N), and the content of impurities (such as O, C, Fe, etc.) is extremely low, which avoids contamination of the deposited film and ensures device performance. They can be adapted to high-end preparation processes such as magnetron sputtering, electron beam evaporation, atomic layer deposition (ALD), etc., to meet the precision requirements of different scenarios. As a non-ferrous metal supplier with more than 20 years of professional experience, FANMETAL can also provide customers with other high-purity and cost-effective metal sputtering targets, such as Nickel Sputtering Targets, Zr702 Zirconium Target, Chromium Target, etc.
CHARACTERISTICS
Excellent physical properties
It has a high melting point, low density, high hardness, strong neutron absorption ability, and can still maintain good structural stability in high-temperature environments.
Electrical and optical properties
The optical transparency and conductivity are very good, which can not only be used to make high-quality optical thin film coatings, but also to adjust the conductive properties of materials.
Good chemical properties
It does not easily react with water, oxygen, and acid at room temperature, and it does not easily undergo chemical reactions when used in combination with other target materials (such as metals and oxides), thus ensuring stable film performance.
Strong molding processing capability
The target size can be customized according to equipment requirements, the composition is highly controllable, which can ensure high sputtering efficiency, and it can be combined with a variety of substrate materials to form a thin film with strong adhesion.
SPECIFICATION
|
Material |
Boron(B) |
|
Purity |
≥99.99%(4N) |
| Diameter | φ20mm-φ300mm |
| Thickness | 2mm~20mm |
| Density | 2.34g/cm3 |
|
Melting Point |
2076 °C |
|
Hardness |
2000-2500 HV |
| Elastic modulus | 400-450 GPa |
|
Surface |
Polished, Alkali Cleaning, Grinding, |
| Standard | ASTM B853 |
|
Certification |
ISO 9001 |
APPLICATION
1. Semiconductor field
In the manufacture of semiconductor devices such as transistors and diodes, Boron B Target is used to provide dopants, which can accurately control the electrical properties of semiconductor materials such as silicon crystals, thereby achieving precise control of the conductive properties of the device.
Preparation of boron-silicon oxide thin films as insulating layers or passivation layers of semiconductor devices, using the diffusion barrier properties of boron to improve device reliability.
2. Magnetic recording field
Preparation of high-performance magnetic films: Boron targets can be used to prepare magnetic recording films with high storage density, low noise, and good thermal stability. In magnetic recording media, the addition of boron can adjust magnetic performance parameters to meet the requirements of modern magnetic storage technology for large capacity, high speed, and high reliability.
3. Aerospace field
The boride coating prepared by high-purity boron targets has an extremely high melting point and thermal shock resistance, and can be used for rocket nozzles and turbine blade surface coatings, which helps to reduce the weight of components while resisting extremely high temperatures and gas corrosion.
4. Hard wear-resistant coating
Boron B Target can form hard coatings on the surfaces of tools, molds, mechanical parts, etc., through processes such as physical vapor deposition or chemical vapor deposition. This coating has the characteristics of high hardness, high wear resistance, and low friction coefficient, which can significantly improve the service life and working efficiency of these components and reduce production costs.
PROCESS
①Physical purification is first performed to ensure a low impurity content, which is conducive to the deposition of high-performance films.
②The high-purity boron powder is subjected to cold pressing sintering or hot isostatic pressing, and the green body is evenly pressed, and the density can reach more than 99%.
③Diamond tool cutting and grinding, and polishing are used to improve dimensional accuracy and reduce surface roughness.
④Annealing treatment is performed in a vacuum atmosphere to eliminate internal stress during the molding process and stabilize the crystal structure.
⑤The final quality control meets ISO9001 standards and meets the stringent requirements of customers.
PICTURES
VIDEO
WHY CHOOSE US
One-stop Solution
After receiving inquiries from customers, we can provide customers with one-stop services such as product quotation, production process, product acceptance, transportation and delivery, and after-sales service. While ensuring product quality, we can also meet customers' different customization requirements.
Competitive prices
Our prices are very reasonable compared to other overseas suppliers and are worthy of our product quality. Moreover, all our products have obtained ISO9001 certification.FANMETAL can provide overseas customers with the most cost-effective non-ferrous metal products.
Advanced Equipment
We have professional CNC machine tools, rolling machines, sintering furnaces, cutting machines, welding equipment and surface treatment equipment. Moreover, our technicians can design drawings and customize production according to customer requirements. They can also go to overseas customers to carry out on-site installation of equipment.
Global Shipping
We cooperate with global logistics companies such as UPS/DHL. Relying on the overseas warehouse layout and local customs clearance team, we can effectively avoid trade barriers, shorten the delivery cycle, ensure the safety and on-time arrival of goods, and significantly reduce operating costs and improve customer satisfaction.
CASE
Boron Round Sputter Target,99.5% Boron Sputtering Targets, Boron Sputtering Target To Singapore
In early February, they said they had received our Boron Round Sputter Target products and praised the processing quality and delivery speed. We had a detailed discussion on the ordering details of the product before shipping. The two parties reached a consensus smoothly and established a very good cooperative relationship. FANMETAL has always been committed to providing high-quality non-ferrous metal products, and has continued to improve its production technology and service attitude. You can order our products with confidence.
PRODUCT QUALIFICATION
