Aluminum Silicon Sputter Target
Overview
Aluminum Silicon Sputter Target is a metal alloy target material manufactured through precision processing of high-purity aluminum-silicon material. It is utilized in various fields due to its advantages of lightweight, wear resistance, high-temperature resistance, corrosion resistance, fast deposition rates, and high-quality film deposition. This target can sputter thin film coatings with diverse properties, including high insulation, high reflectivity, high wear resistance, high transparency, and high thermal conductivity.
Aluminum Silicon Alloy Properties
- High purity and low porosity effectively prevent impurities from interfering with the electrical, optical, and chemical properties of the thin film, ensuring stable performance of the sputtered film.
- High thermal conductivity and low thermal expansion coefficient result in resistance to deformation and excellent heat dissipation.
- High hardness, excellent wear resistance, and good toughness lead to a long service life.
- High sputtering efficiency and high film uniformity significantly improve the corrosion resistance, thermal stability, and electrical insulation properties of the thin film.
Aluminum Silicon Sputter Target Dimension
High aluminum content (>50% aluminum)
- The surface is smoother, and the element distribution is more uniform.
- The interfacial bonding strength is stronger, and the film thickness is greater and more uniform.
- Suitable for applications requiring high mechanical strength, chemical stability, and optical transparency.
High silicon content (>50% silicon)
- The surface is relatively rough, and the element distribution is slightly uneven.
- It offers better electrical insulation and thermal stability.
- Suitable for specific optical applications such as insulating layers and mirrors.
| Grade | Al-20Si |
| Purity | 99.5%,99.7%,99.8%,99.9%,99.95%,99.99% |
| Shape | Round |
| Diameter | Φ50-Φ300mm |
| Thickness | 3-20mm |
| Density | 2.58g/cm³ |
| Hardness | 100-120HV |
| Surface | Polishing, Grinding |
| Delivery Time | 20-30DAYS |
| Certification | ISO 9001 |
Aluminum Silicon Targets Application
1. Industrial Machinery
Aluminum Silicon Sputtering Targets are used to deposit aluminum-silicon coatings on core components such as precision bearings, gears, hydraulic valve cores, mold cavities, and machine tool guide rails. This significantly improves the surface wear resistance and scratch resistance of mechanical parts, making them suitable for various wear-prone working conditions.
2. Automotive Manufacturing
For harsh environments such as automotive chassis and engine surroundings, which are often damp and subject to friction, the coating deposited by the Aluminum Silicon Sputter Target forms a dense Al₂O₃-SiO₂ composite passivation film on the surface, providing both corrosion resistance and wear resistance.
3. Electronics and Semiconductors
The sputtered coating can be used as a protective layer for electrical casings or as a high-hardness isolation layer for semiconductor devices. It not only improves the oxidation resistance of plastic casings but also provides excellent insulation, preventing short circuits in electronic components.
4. Optics and Display Coatings
Used in the manufacture of mirrors, filters, and electrodes for liquid crystal displays (LCD/OLED), it is often used to prepare high-quality insulating films or anti-reflective films.
5. High-End Decoration
The film sputtered from the 8020 aluminum-silicon target exhibits a uniform silver-white metallic luster and possesses wear-resistant and anti-fingerprint properties. It can replace some traditional decorative coatings, making it suitable for high-end hardware, luxury goods, metal casings, and architectural decorative profiles.
Processing
Raw Material Preparation → Vacuum Melting and Casting → Homogenization Annealing → Plastic Working (Forging + Rolling) → Precision Machining → Target Material - Back-Plated Bonding → Finished Product Inspection → Packaging and Shipment
① High-purity aluminum ingots and silicon powder are uniformly blended to prevent impurities from affecting coating performance.
② Aluminum and silicon are layered proportionally into a vacuum induction melting furnace to achieve a fine, uniform grain structure.
③ Cold isostatic pressing provides preliminary shaping, followed by hot pressing and sintering in a vacuum environment to densify the material and form a high-density target blank.
④ Employ a multi-pass hot forging + warm rolling combination process to achieve the base thickness of the finished product, with tolerances controlled within ±0.2mm.
⑤ CNC machining (turning and grinding) to achieve customer-specified dimensions and shapes, followed by backing plate bonding.
⑥ Comprehensive performance verification, including mechanical properties, dimensional accuracy, chemical purity, surface roughness, visual inspection, and flatness, ensuring qualified packaging and shipment.
