Ceriated Tungsten Electrodes
OVERVIEW
Ceriated Tungsten Electrodes are a tungsten electrode material with wolfram as the matrix and cerium oxide (Ce₂O₃) as a dopant. It has become the preferred material for welding operations in aerospace, automobile manufacturing, the electronics industry, medical equipment, and other fields. Its application value is even more prominent in scenarios with high requirements for safety and precision.
CHARACTERISTICS
Excellent arc performance
The addition of cerium oxide reduces the electron work function of wolfram, making it easier to start an arc and maintaining a stable arc shape. The weld has uniform penetration depth and width, a high surface finish, and reduces subsequent grinding processes.
Strong versatility
It performs well in DCEN, DCEP, and AC welding, and can cover a wide range of scenarios from micro-arc welding (such as less than 0.5A) to medium and high current welding (such as hundreds of amperes).
No radioactivity
Traditional thoriated wolfram electrodes are radioactive and may cause potential harm to the health of operators if used for a long time. However, cerium wolfram electrodes do not contain radioactive elements and are environmentally friendly materials. They do not require special protection during operation and storage.
Long service life
Cerium oxide can enhance the high-temperature stability of the wolfram matrix, reduce the evaporation and splashing of wolfram, reduce the electrode loss rate, extend the replacement cycle, further improve production efficiency and reduce consumables costs.
SPECIFICATION
|
Grade |
WCe20 |
|
Purity |
CeO2:1.80-2.20% |
|
Diameter |
1-10mm |
|
Length |
30mm-200mm |
|
Density |
>18.95g/cm3 |
|
Welding Current |
80-140AMPS |
|
Standard |
ASTM, GB, AISI |
|
Certification |
ISO 9001 |
APPLICATION
Ceriated Tungsten Electrodes are suitable for a variety of welding methods, such as tungsten inert gas shielded welding (TIG welding, also known as argon arc welding), plasma arc welding, etc., and are compatible with the welding of various metal materials such as stainless steel, aluminum, copper, titanium, etc., which can meet the needs of micro welding and improve the stability of welding quality.
- Aerospace: used for precision welding of aircraft fuselages, engine components (such as turbine blades, combustion chambers), missile shells, etc., and the connection of spacecraft structural parts (aluminum alloys, titanium alloys, high-temperature alloys).
- Automobile manufacturing: welding of automobile body thin plates (stainless steel, aluminum alloys), welding of structural parts of rail transit vehicles (high-speed rail, subway) (such as frames, door frames).
- Chemical industry: welding of chemical equipment (such as reactors, pipelines, heat exchangers) (stainless steel, Hastelloy alloy, and other corrosion-resistant materials), and sealing welding of high-pressure vessels.
- Energy field: welding of nuclear power equipment (pipelines, pressure vessels), welding of wind power generation equipment.
- Machinery manufacturing: mold repair, welding, wear repair of shaft parts, welding of hardware products, and welding of pipeline interfaces.
- Electronic field: micro welding of sensor leads, chip pins, and other electronic components.
- Medical industry: precision welding of medical devices (such as scalpels and implantable devices).
PROCESS
① Select W powder and cerium oxide (CeO₂) powder with a purity of ≥99.95%, and control the ratio according to the electrode model (such as WC20 contains 2% CeO₂, WC15 contains 1.5% CeO₂).
② Press the mixed powder into a rod-shaped blank with a certain shape and density, and densify the blank by high-temperature sintering while removing impurities.
③ Hot forging or rolling the blank to refine the grains, improve the density and mechanical strength of the electrode, and then anneal it for subsequent precision processing.
④ Process the blank into a finished product (such as a pointed head, round head, flat head) that meets the requirements of use by turning or grinding to ensure surface accuracy and dimensional tolerance.
⑤ Surface cleaning, grinding or polishing to ensure that there is no impurity residue.
⑥ Comprehensive quality inspection, such as component inspection, appearance inspection, arc stability test, etc.
PICTURES
VIDEO
WHY CHOOSE US
One-stop Solution
After receiving the customer's inquiry, we will respond immediately to confirm the customer's needs, such as size specifications and order quantity, and then carry out a series of services such as quotation, customized production, quality inspection, packaging and delivery, after-sales, etc. It is our responsibility to let customers have no worries.
Professional equipment and team
We have a professional technical team and are equipped with advanced production equipment such as vacuum furnaces, CNC machine tools, rolling mills, etc. You can trust our product quality and processing technology.
High-Quality After-Sales
If you have any questions after receiving the product, please feel free to contact us. We will provide the best after-sales solution for customers based on the actual situation, and we can also give you a discount on your next order.
Global Shipping
We have established long-term cooperation with many international logistics companies, such as DHL, UPS, FedEx, and SF Express, and can deliver products to customers on time by land or air transportation. We can effectively avoid trade barriers, shorten the delivery cycle, ensure the safety and on-time arrival of goods, and significantly reduce operating costs and improve customer satisfaction.
CASE
Ceriated Tungsten Electrodes, Cerium Tungsten Electrode To Mexico
Recently, FANMETAL successfully completed the delivery of a batch of high-performance Cerium Tungsten Electrodes to an important customer in Mexico. The smooth delivery of this order not only demonstrates the company's professional strength in the field of non-ferrous metal materials but also marks a solid step forward in the cooperation between the two parties in precision welding materials, laying the foundation for further expansion of the Latin American market. The electrode products supplied to Mexican customers this time strictly follow international quality standards and customer customization requirements, and implement refined management of the entire process from raw material selection to production process control. Relying on advanced rare earth doping technology and precision processing equipment, the company ensures that the product's tungsten content, cerium oxide distribution uniformity and electrode tip accuracy are at the industry-leading level, which can effectively improve welding efficiency, reduce spatter, and meet customers' stringent needs in high-precision welding scenarios.
PRODUCT QUALIFICATION
